Rob’s Special Amplfier

Rob’s Special Amplifier Specifications:

Preamp

  • 5x12AX7

  • Channel 1: Fender Style Channel

    • Bright Enable/Disable

    • Treble

    • Midrange

    • Bass

  • Channel 2: Marshall Channel

    • Foot Switch Selectable Preamp Boost

    • Bass Boost

    • Midrange Boost

    • Bright Enable/Disable

    • Foot Switch Selectable Overdrive

    • Treble, Midrange, Bass

  • Bias Tremolo

    • Speed / Depth

    • Foot Switch Enable/Disable

Power Amp

  • 2x6V6 Power Tubes

  • Negative Feedback Configuration

    • Normal, Loose, None

  • Presence Control

  • Mercury Magnetics Fat Stack Output Transformer

  • Fane Acoustics A60 Speaker

Buffered Effects Loop

  • FET Based FX Send and FX Return

  • Switch Selectable Return Enable

Power Supply

  • GZ34 Rectifier

  • High Capacity Reservoir Capacitors

  • Saftey Bleed Resistors

  • Mercury Magnetics Fat Stack Power Transformer
